StarTech.com 4x4 VGA Video Matrix Switch Splitter with Audio - Share up to four distinct VGA inputs and audio source signals bet

Reference: STCST424MX

Condition: New product

Manufacturer:

99999 Items

$359.99

More info

The ST424MX 4x4 VGA Matrix Switcher/Splitter allows users to share up to four distinct VGA inputs (as well as a corresponding audio source) between four independent displays or projectors. Providing convenient push button control, the VGA Matrix Switcher/Splitter allows each of the four input VGA signals and the corresponding audio, to be switched individually meaning that you can have a different source showing on each display or one source showing on both offering maximum flexibility and control. To ensure optimized VGA distribution and signal management even over longer distance signal transmissions, the ST424MX VGA Matrix Switcher/Splitter features a built-in signal booster that facilitates installation of displays at distances of up to 210ft away from the source device, while maintaining flawless signal integrity. Designed to provide maximum control while saving space and eliminating clutter, the ST424MX can be used as a standalone solution or rack mounted using the (included) ear-mounts. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

General Information
Manufacturer:StarTech.com
Manufacturer Part Number:ST424MX
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:4x4 VGA Video Matrix Switch Splitter with Audio
Marketing Information:

The ST424MX 4x4 VGA Matrix Switcher/Splitter allows users to share up to four distinct VGA inputs (as well as a corresponding audio source) between four independent displays or projectors.

Providing convenient push button control, the VGA Matrix Switcher/Splitter allows each of the four input VGA signals and the corresponding audio, to be switched individually meaning that you can have a different source showing on each display or one source showing on both offering maximum flexibility and control.

To ensure optimized VGA distribution and signal management even over longer distance signal transmissions, the ST424MX VGA Matrix Switcher/Splitter features a built-in signal booster that facilitates installation of displays at distances of up to 210ft away from the source device, while maintaining flawless signal integrity.

Designed to provide maximum control while saving space and eliminating clutter, the ST424MX can be used as a standalone solution or rack mounted using the (included) ear-mounts.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.


Packaged Quantity:1
Product Type:Video Switchbox

Technical Information
Connectivity Technology:Cable
Number of Input Devices Supported:4
Device Supported:
  • Computer
  • Display
  • Projector

Number of Displays Supported:4
Video
Maximum Video Resolution:1920 x 1440
Interfaces/Ports
VGA In:Yes
VGA Out:Yes
Audio Line In:Yes
Audio Line Out:Yes
Number of VGA Inputs:4
Number of VGA Outputs:4
Media & Performance
Maximum Operating Distance:210 ft
Physical Characteristics
Product Color:Black
Form Factor:
  • Rack-mountable
  • Desktop

Height:1.7"
Width:4.3"
Depth:10.6"
Weight (Approximate):2.43 lb
Miscellaneous
Package Contents:
  • 4x4 VGA Video Matrix Switch Splitter with Audio
  • 2 x Ear-mounts for Rack-mounting
  • 1 x Bag of Screws
  • 1 x Universal Power Adapter (US/UK/EU/AUS)
  • 1 x Instruction Manual

Additional Information:
  • Matrix switching functionality gives you full control of what source is shown on each display with the touch of a button.
  • Built-in signal amplifier lets you extend your connection by up to 210 feet.

Environmentally Friendly:Yes
Country of Origin:Taiwan
TAA Compliant:Yes
Warranty
Limited Warranty:2 Year
