APC by Schneider Electric Roof Fan Tray for NetShelter SX 750mm Enclosures - 208 V AC440 CFM - Black
Reference: APWACF504
Condition: New product
Manufacturer: Schneider Electric SA
99999 Items
More info
Roof Fan Tray for NetShelter SX 750mm Enclosures features innovative design allows for fast, easy installation by almost anybody and helps to maintain proper rack temperatures within the enclosure by promoting top to bottom airflow movement.
General Information
Manufacturer:Schneider Electric SA
Manufacturer Part Number:ACF504
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Model:ACF504
Product Name:Roof Fan Tray for NetShelter SX 750mm Enclosures
Marketing Information:
Product Type:Fan Tray
Manufacturer:Schneider Electric SA
Manufacturer Part Number:ACF504
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Model:ACF504
Product Name:Roof Fan Tray for NetShelter SX 750mm Enclosures
Marketing Information:
Roof Fan Tray for NetShelter SX 750mm Enclosures features innovative design allows for fast, easy installation by almost anybody and helps to maintain proper rack temperatures within the enclosure by promoting top to bottom airflow movement.
Product Type:Fan Tray
Technical Information
Maximum Air Flow:440 CFM
Maximum Noise Level (A-Weighted):62 dB(A)
Maximum Air Flow:440 CFM
Maximum Noise Level (A-Weighted):62 dB(A)
Power Description
Input Voltage:208 V AC
Input Voltage:208 V AC
Physical Characteristics
Color Family:Black
Product Color:Black
Height:2.4"
Width:28.5"
Depth:35.2"
Weight (Approximate):22.55 lb
Color Family:Black
Product Color:Black
Height:2.4"
Width:28.5"
Depth:35.2"
Weight (Approximate):22.55 lb
Miscellaneous
Package Contents:Roof Fan Tray for NetShelter SX 750mm Enclosures Installation guide
Additional Information:
Compatibility:
Environmentally Friendly:Yes
Environmental Certification:RoHS
REACH Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=758490&lang=en-us
EU RoHS Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=758490&lang=en-us
REACH free of SVHC:Yes
Country of Origin:Philippines
Package Contents:
Additional Information:
- Cools by exhausting heat out of the roof of the rack
- Audible noise at 1 meter from surface of unit
Input Connections:
- IEC-320 C14
- Schuko CEE 7/7P
Compatibility:
NetShelter SX 750mm Enclosures
Environmentally Friendly:Yes
Environmental Certification:RoHS
REACH Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=758490&lang=en-us
EU RoHS Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=758490&lang=en-us
REACH free of SVHC:Yes
Country of Origin:Philippines
Warranty
Limited Warranty:2 Year
Additional Warranty Information:2 years repair or replace
Limited Warranty:2 Year
Additional Warranty Information:2 years repair or replace
