APC - 5000VA Step-Down Rack-mountable Transformer - 5000VA - 110V AC - 120V AC
Reference: APWAP9628
Condition: New product
Manufacturer: Schneider Electric SA
99999 Items
More info
This product offers rack based designs and fit into any standard 19' rack. The product design is consistent with other APC products. Available in 2U height and deliver up to 4.5 kW to your load. It step down 208V to 120 V for distribution to loads. It is designed to work with the APC Symmetra and Smart-UPS 208V products.
General Information
Manufacturer:Schneider Electric SA
Manufacturer Part Number:AP9628
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Name:5000VA Step-Down Rack-mountable Transformer
Marketing Information:
Product Type:Step Down Transformer
Manufacturer:Schneider Electric SA
Manufacturer Part Number:AP9628
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Name:5000VA Step-Down Rack-mountable Transformer
Marketing Information:
This product offers rack based designs and fit into any standard 19' rack. The product design is consistent with other APC products. Available in 2U height and deliver up to 4.5 kW to your load. It step down 208V to 120 V for distribution to loads. It is designed to work with the APC Symmetra and Smart-UPS 208V products.
Product Type:Step Down Transformer
Technical Information
Power Rating:5000 VA
Input Receptacle Type:Hard Wire 3-wire (2PH + G)
Output Receptacle Type:Hard Wire 3-wire (H N + G)
Output Receptacle Detail:1 x Hard Wire 3-wire (H N + G)
Power Rating:5000 VA
Input Receptacle Type:Hard Wire 3-wire (2PH + G)
Output Receptacle Type:Hard Wire 3-wire (H N + G)
Output Receptacle Detail:1 x Hard Wire 3-wire (H N + G)
Power Description
Input Voltage:208 V
Output Voltage:120 V AC
Maximum Line Current:26 A
Input Voltage:208 V
Output Voltage:120 V AC
Maximum Line Current:26 A
Physical Characteristics
Color Family:Black
Product Color:Black
Form Factor:Rack-mountable
Rack Height:2U
Height:3.5"
Width:17.5"
Depth:24"
Weight (Approximate):95.20 lb
Color Family:Black
Product Color:Black
Form Factor:Rack-mountable
Rack Height:2U
Height:3.5"
Width:17.5"
Depth:24"
Weight (Approximate):95.20 lb
Miscellaneous
Package Contents:5000VA Step-Down Rack-mountable Transformer Rack mounting brackets User manual
Certifications & Standards:CSA|UL Listed
Environmentally Friendly:Yes
Environmental Certification:RoHS
Green Premium:Yes
Optimized Energy Efficiency:Yes
Product Take Back Program:Yes
Mercury Free:Yes
RoHS Exemption Information:https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP9635_ROHS_DECLARATION&p_FileName=AP9635KIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759642&lang=en-us
EU RoHS Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759642&lang=en-us
Environmental Profile Availability:https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1512011_V1
End of Life Manual Availability:https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512011_V1
REACH free of SVHC:No
Lead Free:Yes
Package Contents:
Certifications & Standards:CSA|UL Listed
Environmentally Friendly:Yes
Environmental Certification:RoHS
Green Premium:Yes
Optimized Energy Efficiency:Yes
Product Take Back Program:Yes
Mercury Free:Yes
RoHS Exemption Information:https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP9635_ROHS_DECLARATION&p_FileName=AP9635KIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759642&lang=en-us
EU RoHS Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759642&lang=en-us
Environmental Profile Availability:https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1512011_V1
End of Life Manual Availability:https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512011_V1
REACH free of SVHC:No
Lead Free:Yes
Warranty
Limited Warranty:2 Year
Additional Warranty Information:2 years repair or replace
Limited Warranty:2 Year
Additional Warranty Information:2 years repair or replace
