StarTech.com 1 Port Flush Mount ExpressCard SuperSpeed USB 3.0 Card Adapter with UASP Support - 5Gbps - Add a USB 3.0 port conne
Reference: STCECUSB3S11
Condition: New product
Manufacturer: StarTech.com
99999 Items
More info
The ECUSB3S11 Flush Mount 1-Port USB 3.2 Gen 1 ExpressCard lets you add a single USB 3.2 Gen 1 port connection to your laptop through an ExpressCard slot. The USB 3.2 Gen 1 adapter uses a unique form factor design that allows it to sit fully in a standard 34mm ExpressCard slot without sticking out. The port sits virtually flush with the sides of the laptop, enabling you to leave the card installed even while on the move, without fear of damage to the card or slot. Enhanced with UASP support (USB Attached SCSI Protocol), this USB 3.2 Gen 1 controller performs up to 70% faster than conventional USB 3.2 Gen 1 when paired with a (Note: UASP requires a compatible operating system). Using a more efficient protocol than the traditional USB BOT (Bulk-Only Transport), UASP technology optimizes transfers by allowing multiple commands to be processed simultaneously, significantly increasing transfer speeds for less wait time on data transfers. See our UASP test results below for further details. The USB 3.2 Gen 1 ExpressCard adapter supports data transfer rates up to 5Gbps, and is still backward compatible with USB 2.0 at up to 480Mbps, or USB 1.1/1.0 at up to 12/1.5 Mbps respectively. Backed by a StarTech.com 2-year warranty and free lifetime technical support. UASP is supported in Windows 8, Server 2012 and Linux kernel 2.6.3 or later. In testing UASP performed with up to a 70% faster read / 40% faster write speed over traditional USB 3.2 Gen 1 at peak performance. At the same peak in testing, UASP also showed up to an 80% reduction in required processor resources. Test results were obtained using an Intel Ivy Bridge system, StarTech.com add-on USB 3.2 Gen 1 cards, a UASP-enabled StarTech.com enclosure, and a SATA III solid state drive.
General Information
Manufacturer:StarTech.com
Manufacturer Part Number:ECUSB3S11
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:1 Port Flush Mount ExpressCard SuperSpeed USB 3.0 (5Gbps) Card Adapter
Marketing Information:The ECUSB3S11 Flush Mount 1-Port USB 3.2 Gen 1 ExpressCard lets you add a single USB 3.2 Gen 1 port connection to your laptop through an ExpressCard slot.
The USB 3.2 Gen 1 adapter uses a unique form factor design that allows it to sit fully in a standard 34mm ExpressCard slot without sticking out. The port sits virtually flush with the sides of the laptop, enabling you to leave the card installed even while on the move, without fear of damage to the card or slot.
Enhanced with UASP support (USB Attached SCSI Protocol), this USB 3.2 Gen 1 controller performs up to 70% faster than conventional USB 3.2 Gen 1 when paired with a (Note: UASP requires a compatible operating system). Using a more efficient protocol than the traditional USB BOT (Bulk-Only Transport), UASP technology optimizes transfers by allowing multiple commands to be processed simultaneously, significantly increasing transfer speeds for less wait time on data transfers. See our UASP test results below for further details.
The USB 3.2 Gen 1 ExpressCard adapter supports data transfer rates up to 5Gbps, and is still backward compatible with USB 2.0 at up to 480Mbps, or USB 1.1/1.0 at up to 12/1.5 Mbps respectively.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
UASP is supported in Windows 8, Server 2012 and Linux kernel 2.6.3 or later. In testing UASP performed with up to a 70% faster read / 40% faster write speed over traditional USB 3.2 Gen 1 at peak performance.
At the same peak in testing, UASP also showed up to an 80% reduction in required processor resources.
Test results were obtained using an Intel Ivy Bridge system, StarTech.com add-on USB 3.2 Gen 1 cards, a UASP-enabled StarTech.com enclosure, and a SATA III solid state drive.
Manufacturer:StarTech.com
Manufacturer Part Number:ECUSB3S11
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:1 Port Flush Mount ExpressCard SuperSpeed USB 3.0 (5Gbps) Card Adapter
Marketing Information:The ECUSB3S11 Flush Mount 1-Port USB 3.2 Gen 1 ExpressCard lets you add a single USB 3.2 Gen 1 port connection to your laptop through an ExpressCard slot.
The USB 3.2 Gen 1 adapter uses a unique form factor design that allows it to sit fully in a standard 34mm ExpressCard slot without sticking out. The port sits virtually flush with the sides of the laptop, enabling you to leave the card installed even while on the move, without fear of damage to the card or slot.
Enhanced with UASP support (USB Attached SCSI Protocol), this USB 3.2 Gen 1 controller performs up to 70% faster than conventional USB 3.2 Gen 1 when paired with a (Note: UASP requires a compatible operating system). Using a more efficient protocol than the traditional USB BOT (Bulk-Only Transport), UASP technology optimizes transfers by allowing multiple commands to be processed simultaneously, significantly increasing transfer speeds for less wait time on data transfers. See our UASP test results below for further details.
The USB 3.2 Gen 1 ExpressCard adapter supports data transfer rates up to 5Gbps, and is still backward compatible with USB 2.0 at up to 480Mbps, or USB 1.1/1.0 at up to 12/1.5 Mbps respectively.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
UASP is supported in Windows 8, Server 2012 and Linux kernel 2.6.3 or later. In testing UASP performed with up to a 70% faster read / 40% faster write speed over traditional USB 3.2 Gen 1 at peak performance.
At the same peak in testing, UASP also showed up to an 80% reduction in required processor resources.
Test results were obtained using an Intel Ivy Bridge system, StarTech.com add-on USB 3.2 Gen 1 cards, a UASP-enabled StarTech.com enclosure, and a SATA III solid state drive.
Packaged Quantity:1
Product Type:USB Adapter
Technical Information
Host Interface:ExpressCard/34
Host Interface:ExpressCard/34
Media & Performance
UASP Support:Yes
UASP Support:Yes
Interfaces/Ports
Total Number of USB Ports:1
Number of USB 3.2 Ports:1
Total Number of USB Ports:1
Number of USB 3.2 Ports:1
Software
Operating System Supported:
Operating System Supported:
- Windows Vista
- Windows 7
- Windows 8
- Windows 8.1
- Windows 10
- Windows 11
- Windows Server 2008 R2
- Windows Server 2012
- Windows Server 2016
- Windows Server 2019
- Linux 4.11.x
Physical Characteristics
Product Color:
Form Factor:Plug-in Module
Height:0.2"
Width:1.3"
Length:3"
Weight (Approximate):0.80 oz
Product Color:
- Silver
- Black
Form Factor:Plug-in Module
Height:0.2"
Width:1.3"
Length:3"
Weight (Approximate):0.80 oz
Miscellaneous
Package Contents:
Platform Supported:PC
Environmentally Friendly:Yes
Environmental Certification:
Country of Origin:Taiwan
TAA Compliant:Yes
Package Contents:
- 1 Port Flush Mount ExpressCard SuperSpeed USB 3.0 (5Gbps) Card Adapter
- 1 x DC to USB Adapter Cable
- 1 x 34mm to 54mm Stabilizer Bracket
- 1 x Driver CD
- 1 x Instruction Manual
Platform Supported:PC
Environmentally Friendly:Yes
Environmental Certification:
- RoHS
- REACH
- WEEE
Country of Origin:Taiwan
TAA Compliant:Yes
Warranty
Limited Warranty:2 Year
Limited Warranty:2 Year
