APC by Schneider Electric ACF201BLK Rack Side Air Distribution System - 260 CFM - Rack-mountable - Black - IT - Black - 2U - 120

Reference: APWACF201BLK

Condition: New product

Manufacturer:

99999 Items

$1,124.99

More info

Housing equipment with side to side airflow creates many challenges for IT and facility managers, particularly in regards to cooling. Because most enclosures are designed for a front to back airflow pattern, it is difficult to maintain ideal operating temperatures on side to side airflow equipment. The Rack Side Air Distribution Unit is a 2U rack mountable air distribution product for networking equipment or servers with side to side airflow. It pulls in conditioned air from the front of the rack and distributes it to the side air intake of the networking equipment.

General Information
Manufacturer:Schneider Electric SA
Manufacturer Part Number:ACF201BLK
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Model:ACF201BLK
Product Name:ACF201BLK Rack Side Air Distribution System
Marketing Information:

Housing equipment with side to side airflow creates many challenges for IT and facility managers, particularly in regards to cooling. Because most enclosures are designed for a front to back airflow pattern, it is difficult to maintain ideal operating temperatures on side to side airflow equipment. The Rack Side Air Distribution Unit is a 2U rack mountable air distribution product for networking equipment or servers with side to side airflow. It pulls in conditioned air from the front of the rack and distributes it to the side air intake of the networking equipment.


Product Type:Airflow Cooling System
Technical Information
Maximum Air Flow:260 CFM
Application/Usage:IT
Plug Type:NEMA 5-15P
Receptacle Type:IEC 60320 C13
Controls/Indicators
Indicators & Controls:Power On/Off
Power Description
Input Voltage:120 V
Power Consumption:150 W
Plug/Connector Type:IEC 60320 C13
Physical Characteristics
Form Factor:Rack-mountable
Compatible Rack Height:2U
Color Family:Black
Product Color:Black
Height:3.4"
Width:17"
Depth:26.3"
Weight (Approximate):32.10 lb
Miscellaneous
Package Contents:
  • ACF201BLK Rack Side Air Distribution System
  • Installation Guide
  • Rack Mounting Brackets
  • User Manual

Certifications & Standards:UL Recognized
Environmentally Friendly:Yes
Mercury Free:Yes
RoHS Exemption Information:https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=ACF202BLK_ROHS_DECLARATION&p_FileName=ACF202BLKKIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=758476&lang=en-us
EU RoHS Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=758478&lang=en-us
REACH free of SVHC:Yes
Warranty
Limited Warranty:2 Year
Additional Warranty Information:2 years repair or replace
